Electrodeposition bath saccharin additive (saccharin sodium / saccharin soluble, electroplating grade) is a high-purity organic additive designed for electroplating and electrodeposition bath formulations.
Chemical Identity & Key Identifiers
Chemical Name: Saccharin Sodium / 1,2-Benzisothiazol-3(2H)-one 1,1-dioxide sodium salt
CAS Number: 128-44-9 (Dihydrate: 6152-67-2)
EC / EINECS No.: 204-874-6
HS Code: 2925.1100
Molecular Formula: C7H4NNaO3S · 2H2O
Molecular Weight: 241.19 g/mol (Dihydrate)
Physical Appearance: White crystalline powder or granular crystals
Technical Specifications
|
Parameter |
Product Specification |
Test Method / Reference |
|
Product Grade |
Electroplating Grade (Soluble) |
In-house / Customer standard |
|
Appearance |
White crystalline powder or fine granules |
Visual inspection |
|
Assay (Dry Basis) |
>= 99.0% |
Titration / HPLC |
|
Loss on Drying (Moisture) |
<= 15.0% (Dihydrate standard) |
Gravimetric (140°C) |
|
pH (10% Aqueous Solution) |
6.0 – 7.5 |
Potentiometric |
|
Water Solubility |
Fully soluble (>= 200 g/L at 20°C) |
Visual / Solubilization test |
|
Heavy Metals (as Pb) |
<= 10 ppm |
AAS / ICP-OES |
|
Arsenic (As) |
<= 2 ppm |
AAS |
|
Clarity of Solution |
Clear and colorless |
Colorimetric |
|
Batch / Lot Traceability |
Unique lot ID assigned to every production run |
Traceability system |
|
Documentation |
COA, TDS, GHS-compliant SDS available |
Quality Control System |
Applications & Functional Performance
Nickel Electroplating (Watts & Sulfamate Baths)
Internal Stress Reduction: Acts as a Class I additive to neutralize tensile stress, preventing peeling, pitting, or micro-cracking in thick deposits.
Grain Refinement: Promotes fine-grained crystal growth for higher brightness and superior physical ductility.
Synergistic Action: Combines effectively with Class II brighteners (e.g., PPS, BEO) to yield uniform, high-leveling mirror finishes.
Electroplating Chemical Formulation
Designed as a key raw material for proprietary additive formulations, brightener concentrates, and stress-reducing maintenance blends.
Features rapid dissolution behavior and excellent compatibility with common bath surfactants, wetting agents, and primary brighteners.
Industrial Metal Finishing & Functional Coatings
Suitable for both decorative chrome-nickel stacks and functional engineering nickel coatings (e.g., electronics, automotive parts, tooling).
Helps maintain consistent plating performance across varying current density ranges (1 - 6 A/dm²).
Laboratory & Process Optimization
Available in laboratory sample quantities for:
- Stress-measurement studies (e.g., via spiral contractometer or bent strip test)
- Hull cell evaluation and bath formulation optimization.
- Raw material qualification and comparative validation.
Quality Control & Compliance
Raw Material Qualification: Strict testing of raw inputs prior to reaction and crystallization stages.
Controlled Batch Processing: Automated temperature and pH controls during crystallization to ensure uniform particle size and purity.
In-Process Quality Checks: Real-time sampling during purification and drying stages.
Finished Product Testing: Comprehensive testing per batch for assay, moisture, clarity, and trace metals.
Regulatory Compliance: Manufactured under ISO 9001:2015 quality management systems. Fully compliant with EU REACH, RoHS, and GHS SDS standards.
Lot Traceability & Retained Samples: Every batch is linked to its COA and retain samples are archived for a minimum of 24 months.
Packaging, Logistics & Supply Chain
Laboratory Samples: 100 g – 1 kg sealed aluminum foil pouches.
Trial & Standard Orders: 25 kg fiber drums or moisture-barrier PE-lined woven bags.
Bulk Orders: 500 kg / 1000 kg palletized super-sacks with stretch wrap.
FAQ
Q: What is the role of Saccharin Sodium in nickel electroplating?
A: Saccharin Sodium acts as a Class I organic additive and stress reliever. It lowers internal tensile stress in the nickel deposit, improves ductility, and refines crystal structure, preventing plating cracks or flaking.
Q: What is the difference between insoluble saccharin and saccharin sodium for plating?
A: Saccharin Sodium (CAS 128-44-9) is readily soluble in water (>= 200 g/L), making it ideal for direct addition into aqueous plating baths. Insoluble saccharin (CAS 81-07-2) requires pre-dissolution in alkaline solutions before use.
Q: What is the recommended dosage in a Watts nickel bath?
A: Typical concentrations range from 0.5 g/L to 2.0 g/L, depending on current density, bath temperature, and secondary brightener concentration. Exact dosage should be validated using Hull cell tests.
Q: Can you supply REACH-compliant material for the European market?
A: Yes. Regulatory documentation including REACH compliance statements, GHS-compliant SDS, and Certificate of Analysis (COA) are provided with every shipment.
Q: Can we request a sample for laboratory evaluation?
A: Yes. We provide 100 g to 500 g lab evaluation samples along with a batch-specific COA and Technical Data Sheet (TDS).
